1. APPLICATION
Suitable for all gas and liquid media that will not obstruct the pressure system or attack copper alloy parts. Specially designed for difficult conditions of use, as there are vibrations or quick changes of pressure. Also useful for adverse ambients.
Designation | Stainless steel case, crimped ring, liquid fillable |
Applications | Adverse service conditions where pulsation or vibration exists |
Nominal size: (mm) | Ø(100) |
Scale ranges | - 1 to 600 bar |
Accuracy class | 1.0 Ø (100) |
Pressure connection | One piece sealing design 1/4" Ø(63) |
Wetted parts | Copper alloy |
Case material | Stainless Steel, crimped ring, bottom connection case without groove, back connection case with L type groove for round bracket |
Window | Polycarbonate |
IP class | IP 65 |
Options/notes | Lower, back entry, Ø100panel mount or surface mount |
